Supply Issuance

Contents

• Annual Inflation Rate

• Daily Inflation Rate

• Coinbase Issuance (Continuous Issuance)

• Total Issuance

• Puell Multiple Total

• Puell Multiple, Coinbase Issuance

• ​Daily Supply Inflation Rates​

• ​Annual Supply Inflation Rates

Annual Inflation Rate

Definition

The percentage of new native units (continuous) issued on that day, extrapolated to one year (i.e., multiplied by 365), and divided by the current supply on that day. Sometimes referred to as the annual inflation rate.

Name	MetricID	Unit	Interval
Annual Inflation Rate	IssContPctAnn	Dimensionless	1 year

Details

• This metric can be seen as the asset’s annualized inflation rate. Note that it only includes the predictable inflation, some other emission schedule could happen that would lead to this metric under-estimating the inflation.

• Computed as 100 * IssContNtv * 365 / SplyCur

• A value of 1.0 means that the asset’s supply will increase by 1% per year.

• This metric extrapolates the issuance rate from the current day’s issuance. It doesn’t take into account changes that will happen after the day of this metric’s computation like ETH unpredictable changes in monetary policy (no forward knowledge).

Chart

Source: CM Network Data Charts

Asset-Specific Details

• For XLM, the inflation process is considered continuous issuance as it is protocol mandated and predictable.

Release History

• Released in the 1.0 release of NDP

Interpretation

While colloquially referred to as the inflation rate, this should be understood as supply inflation, not the conventional understanding of inflation as a decline in purchasing power driven by new supply. This metric might more appropriately be called the annualized issuance rate. Coins already existing in circulation but held in an encumbered state (like XRP being released from escrow) are not included in the measure as they are already incorporated in supply.

See Also

• Daily Inflation Rate

Availability for Assets

Coin Metrics CoverageCoin Metrics Coverage

Daily Inflation Rate

Definition

The percentage of new native units (continuous) issued on that day divided by the current supply on that day. Also referred to as the daily inflation rate.

Name	MetricID	Unit	Interval
Daily Inflation Rate	IssContPctDay	Dimensionless	1 day

Details

• This metric can be seen as the asset’s daily inflation rate. Note that it only includes the predictable inflation, some other emission schedule could happen that would lead to this metric under-estimating the inflation.

• Computed as 100 * IssContNtv / SplyCur

• Also equivalent to IssContPctAnn / 365

• A value of 1.0 means that the asset’s monetary policy is a 1% daily inflation.

Chart

Source: CM Network Data Chart

Asset-Specific Details

• For XLM, the inflation process is considered continuous issuance as it is protocol mandated and predictable.

Release History

• Released in the 1.0 release of NDP

See Also

• Annual Inflation Rate

Availability for Assets

Coin Metrics CoverageCoin Metrics Coverage

Coinbase Issuance (Continuous Issuance)

Definition

The sum of supply units issued that day. Only those native units that are issued by a protocol-mandated continuous emission schedule are included.

Name	MetricID	Unit	Interval
Coinbase Issuance (native units)	IssContNtv	Native units	1 day, 1 hour
Coinbase Issuance (USD)	IssContUSD	USD	1 day

Details

• Most protocols have a fixed monetary policy that describes how many native units must be issued per block. This metric tracks those policies.

• It includes founders and community rewards if their amounts are predictable.

• 1 hour frequency is available for ETH_CL only.

Asset-Specific Details

• For XLM, the inflation process is considered continuous issuance as it is protocol mandated and predictable.

• For ETH, prior to the Beacon Chain Launch, this metric captures the rewards issued from mining only. After the beacon chain launch and before the merge, this metric includes both rewards paid out as part of the mining process on the execution layer, as well as rewards paid out in the beacon chain as part of staking. Post merge, this metric captures rewards paid out on the consensus layer (and is equivalent to the value for ETH_CL for this metric).

  • To get the rewards on the ETH Consnsus layer, refer to this metric for the ETH_CL ticker.

• For SOL, counts all rewards paid as part of Voting or Staking rewards. Does not include Rent or Fee rewards

Release Details

• Released in the 1.0 release of NDP

Availability for Assets

Coin Metrics CoverageCoin Metrics Coverage

Coin Metrics CoverageCoin Metrics Coverage

Total Issuance

Definition

The sum of all new supply units issued that day.

Name	MetricID	Unit	Interval
Total Issuance (native units)	IssTotNtv	Native units	1 day, 1 hour
Total Issuance (USD)	IssTotUSD	USD	1 day

Details

• In this metric, compared to the continuous one, all sources of issuance are taken into account.

• This metric is the gross issuance: if in the same day, 100 units are issued and 10 burned, this metric’s value will be 100, not 90 (which would be the net issuance).

• 1 hour frequency is available for ETH_CL only.

Asset-Specific Details

• For Ethereum total issuance differs between the eth and eth_cl ticker.

  • The total issuance for the eth ticker is the total amount of ETH tokens issued in the Ethereum network. This is equivalent to rewards issued on the network which are also captured in Coinbase Issuance.

  • The total issuance for the eth_cl ticker represents all new ETH tokens issued on the consensus layer. This is equivalent to rewards issued plus any new deposits made to the consensus layer.

Release History

• Released in the 1.0 release of NDP

Availability for Assets

Coin Metrics CoverageCoin Metrics Coverage

Coin Metrics CoverageCoin Metrics Coverage

Puell Multiple, Coinbase Issuance

Definition

The ratio of the USD value of new issuance during the period to the 365-day moving average of the USD value of new issuance. Only those native units that are issued by a protocol-mandated continuous emission schedule are included (i.e., units manually released from escrow or otherwise disbursed are not included).

Name	MetricID	Unit	Interval
Puell Multiple, Coinbase Issuance	PuellMulCont	Dimensionless	365 days

Details

• Computed as IssContUSD/ma365(IssContUSD)

Release History

• Release Version: NDP-EOD 4.8 (Nov, 2020)

Interpretation

The Puell Multiple provides insight into market cycles from a mining revenue perspective. Because miners are sometimes considered compulsory sellers given their fixed costs (e.g., equipment, electricity), metric provides insight into the supply side of a cryptoasset's economy. The idea being, that periods where the Puell Multiple is extremely low could be buying opportunities for investors, and periods where it is extremely high could indicate a profit-taking/selling opportunities.

See Also

• Puell Multiple, Revenue

Availability for Assets

Coin Metrics CoverageCoin Metrics Coverage

Puell Multiple, Total Issuance

Definition

The ratio of the USD value of all new issuance during the period to the 365-day moving average of the USD value of all new issuance.

Name	MetricID	Unit	Interval
Puell Multiple, Total Issuance	PuellMulTot	Dimensionless	365 days

Details

• Computed as IssTotUSD/ma365(IssTotUSD)

• Created by David Puell

Release History

• Release Version: NDP-EOD 4.8 (Nov, 2020)

Interpretation

The Puell Multiple provides insight into market cycles from a mining revenue perspective. Because miners are sometimes considered compulsory sellers given their fixed costs (e.g., equipment, electricity), this metric provides insight into the supply side of a cryptoasset's economy. The idea being, that periods where the Puell Multiple is extremely low could be buying opportunities for investors, and periods where it is extremely high could indicate a profit-taking/selling opportunities.

See Also

• Puell Multiple, Revenue

Availability for Assets

Coin Metrics CoverageCoin Metrics Coverage

Daily Supply Inflation Rates

Definition

The percent one-day change in supply. Also referred to as the daily inflation rate. Also available at a 30, 90, 180 day and 1 year moving average.

Name	MetricID	Unit	Interval
Daily Inflation Rate	InfPct	Dimensionless	1d
Inflation Rate 30-Day Average	InfPct30dAvg	Dimensionless	1d
Inflation Rate 90-Day Average	InfPct90dAvg	Dimensionless	1d
Inflation Rate 180-Day Average	InfPct180dAvg	Dimensionless	1d
Inflation Rate 1-Year Average	InfPct1yAvg	Dimensionless	1d

Details

• $InfPct=\frac{SplyCur(n-1)-SplyCur(n)}{SplyCur(n-1)}*100$

• $InfPct[N]Avg=\frac{SplyCur(n-N)-SplyCur(n)}{SplyCur(n-N)}*100$ where N is the days over which to average. This means that for a 30-Day average the formula would be: $InfPct30dAvg=\frac{SplyCur(n-30d)-SplyCur(n)}{SplyCur(n-30d)}*100$

Interpretation

The Inflation rate of the asset over the timeframe defined in the metric. For example, Inflation Rate 1-Year Average shows what the daily inflation rate was based on the supply 1y ago and today.

Availability for Assets

Coin Metrics CoverageCoin Metrics Coverage

Annual Supply Inflation Rates

Definition

The percent change in supply over 1 year. Also referred to as the annual inflation rate. Also available at a 30, 90, 180 day and 1 year moving average.

Name	MetricID	Unit	Interval
Annualized Compounding Inflation Rate	InfPctAnn	Dimensionless	1d
Annualized Compounding Inflation Rate 30-Day Average	InfPctAnn30dAvg	Dimensionless	1d
Annualized Compounding Inflation Rate 90-Day Average	InfPctAnn90dAvg	Dimensionless	1d
Annualized Compounding Inflation Rate 180-Day Average	InfPctAnn180dAvg	Dimensionless	1d
Annualized Compounding Inflation Rate 1-Year Average	InfPctAnn1yAvg	Dimensionless	1d

Details

• $InfPctAnn=((1+\frac{InfPct}{100})^{365}-1)*100$

• $InfPctAnn[N]Avg=(1+\frac{InfPct[N]Avg}{100})^{365}-1$ where N is the days over which to average. This means that for a 30-Day average the formula would be: $InfPctAnn30dAvg=(1+\frac{InfPct30dAvg}{100})^{365}-1$

Availability for Assets

Coin Metrics CoverageCoin Metrics Coverage

API Endpoints

Supply Issuance metrics can be accessed using these endpoints:

• timeseries/asset-metrics

and by passing in the metric ID's Iss* in the metrics parameter.

Asset metrics

get

Returns requested metrics for specified assets. Results for block by block metrics (1b frequency) are ordered by tuple (asset, height, block_hash), all other metrics are ordered by tuple (asset, time). You can change the sorting using sort query parameter. Supported output formats are json (default) and csv, use format query parameter to override it. To fetch the next page of results use next_page_url JSON response field or x-next-page-url CSV HTTP header if present. If multiple metrics are requested in the same time the strict policy for partially available metrics among requested ones is applied:

Authorizations

Query parameters

assetsstring[]required

Comma separated list of assets. Use the /catalog-all/assets endpoint for the full list of supported assets or specify asterisk (*) in order to get metrics for all supported assets.

metricsstring[]required

Comma separated metrics to request time series data for. Information on all available metrics can be found on page https://coverage.coinmetrics.io/asset-metrics-v2. Use the /catalog-all/metrics or /catalog-all/assets endpoint for the full list of supported metrics per asset.

Example: ["AdrActCnt","BlkHgt"]

frequencystring · default: "1d"optional

Frequency of the metrics. Supported values are 1b (block by block), 1s (one second), 1m (one minute), 5m (five minutes), 10m (ten minutes), 1h (one hour), 1d (one day), 1d-ny-close (one day at New York close time). Please refer to the /catalog/metrics endpoint for the full list. Use the /catalog-all/assets endpoint for the full list of supported frequencies per asset-metric pair.

Example: 1b

statusstring · enum · default: "all"optional

Which metric values do you want to see. Applicable only for "reviewable" metrics. You can find them in the /catalog/metrics endpoint.

Available options:

start_timestringoptional

Start of the time interval. This field refers to the time field in the response. Multiple formats of ISO 8601 are supported: 2006-01-20T00:00:00Z, 2006-01-20T00:00:00.000Z, 2006-01-20T00:00:00.123456Z, 2006-01-20T00:00:00.123456789Z, 2006-01-20, 20060120. Inclusive by default. Mutually exclusive with start_height and start_hash. UTC timezone by default. Z suffix is optional and timezone parameter has a priority over it. If start_time is omitted, response will include time series from the earliest time available.

end_timestringoptional

End of the time interval. This field refers to the time field in the response. Multiple formats of ISO 8601 are supported: 2006-01-20T00:00:00Z, 2006-01-20T00:00:00.000Z, 2006-01-20T00:00:00.123456Z, 2006-01-20T00:00:00.123456789Z, 2006-01-20, 20060120. Inclusive by default. Mutually exclusive with end_height and end_hash. UTC timezone by default. Z suffix is optional and timezone parameter has a priority over it. If end_time is omitted, response will include time series up to the latest time available.

start_heightinteger · int64optional

The start height indicates the beginning block height for the set of data that are returned. Inclusive by default. Mutually exclusive with start_time and start_hash.

end_heightinteger · int64optional

The end height indicates the ending block height for the set of data that are returned. Inclusive by default. Mutually exclusive with end_time and end_hash. This parameter is disabled for Community users.

start_hashstringoptional

The start hash indicates the beginning block height for the set of data that are returned. Inclusive by default. Mutually exclusive with start_time and start_height.

end_hashstringoptional

The end hash indicates the ending block height for the set of data that are returned. Inclusive by default. Mutually exclusive with end_time and end_height.

start_inclusiveboolean · default: trueoptional

Inclusive or exclusive corresponding start_* parameters.

end_inclusiveboolean · default: trueoptional

Inclusive or exclusive corresponding end_* parameters.

min_confirmationsinteger · int32 · max: 99optional

Specifies how many blocks behind the chain tip block by block metrics (1b frequency) are based on. Default for btc is 2 and 99 for eth. For example, a min_confirmations of 0 means metrics are being calculated for the block at the tip of the chain (the latest block received by our node) whereas a min_confirmations of 6 means that metrics are being applied to the block that is 6 blocks behind the chain tip (i.e., the 7th block if the chain tip is block 1).

timezonestring · default: "UTC"optional

Timezone name for start_time and end_time timestamps. This parameter does not modify the output times, which are always UTC. Format is defined by TZ database.

Example: America/New_York

page_sizeinteger · int32 · min: 1 · max: 10000 · default: 100optional

Number of items per single page of results. The value of this parameter is ignored if the endpoint supports the format parameter and its value is set to json_stream.

paging_fromstring · enum · default: "end"optional

Where does the first page start, at the start of the interval or at the end. The value of this parameter is ignored if the endpoint supports the format parameter and its value is set to json_stream.

Available options:

sortstring · enum · default: "asset"optional

How results will be sorted. Metrics with 1b frequency are sorted by (asset, height, block_hash) tuples by default. Metrics with other frequencies are sorted by (asset, time) by default. If you want to sort 1d metrics by (time, asset) you should choose time as value for the sort parameter. Sorting by time is useful if you request metrics for a set of assets.

Available options:

limit_per_assetinteger · int32optional

How many entries per asset result should contain. For example, this combination of parameters assets=btc,eth&metrics=ReferenceRate&limit_per_asset=1 returns the latest ReferenceRate values for btc and eth.

prettyboolean · default: falseoptional

Human-readable formatting of JSON responses.

formatstring · enum · default: "json"optional

Format of the response.

Available options:

null_as_zeroboolean · default: falseoptional

Nulls are represented as zeros in the response.

next_page_tokenstringoptional

Token for receiving the results from the next page of a query. Should not be used directly. To iterate through pages just use next_page_url response field.

ignore_forbidden_errorsboolean · default: falseoptional

Ignore "forbidden" errors for the items you currently don't have access to.

ignore_unsupported_errorsboolean · default: falseoptional

Ignore "unsupported" errors for not currently supported by Coin Metrics items.

Responses

application/jsontext/csv

application/json

application/json

application/json

cURL

JavaScript

Python

HTTP

cURL

curl -L \
  --url 'https://api.coinmetrics.io/v4/timeseries/asset-metrics?assets=text&metrics=AdrActCnt'

200

400

401

403

414

200

application/json

text/csv

application/json

Example of a message with daily metrics.

Example of a message with block by block metrics.

Example of a message with 1s metrics.

Example of a message with daily metrics.

{
  "data": [
    {
      "asset": "btc",
      "time": "2020-02-29T00:00:00.000000000Z",
      "PriceUSD": "8582.09029964933",
      "SplyBMXNtv": "283220.10827406",
      "SplyBMXNtv-status": "reviewed",
      "SplyBMXNtv-status-time": "2020-03-01T09:59:13.847251000Z"
    },
    {
      "asset": "btc",
      "time": "2020-03-01T00:00:00.000000000Z",
      "PriceUSD": "8541.77389392169",
      "SplyBMXNtv": "284691.32323907",
      "SplyBMXNtv-status": "reviewed",
      "SplyBMXNtv-status-time": "2020-03-02T14:00:02.622168000Z"
    }
  ],
  "next_page_token": "0.MjAyMC0wNi0wN1QwMDowMDowMFo,MjAyMC0wNi0wN1QwMDowMDowMFo",
  "next_page_url": "https://api.coinmetrics.io/v4/timeseries/asset-metrics?api_key=<your_key>&pretty=true&assets=btc&metrics=SplyBMXNtv,PriceUSD&page_size=2&next_page_token=0.MjAyMC0wNi0wN1QwMDowMDowMFo,MjAyMC0wNi0wN1QwMDowMDowMFo"
}

Time series of metrics for an asset.

Shell

curl --compressed "https://api.coinmetrics.io/v4/timeseries/asset-metrics?metrics=IssContNtv&assets=btc&pretty=true&api_key=<your_key>"

Python

import requests
response = requests.get('https://api.coinmetrics.io/v4/timeseries/asset-metrics?metrics=IssContNtv&assets=btc&pretty=true&api_key=<your_key>').json()
print(response)

Python Client

from coinmetrics.api_client import CoinMetricsClient

api_key = "<API_KEY>"
client = CoinMetricsClient(api_key)

print(
    client.get_asset_metrics(
        metrics="IssContNtv",
        assets="btc",
    ).to_dataframe()
)
