# Analyzing DeFi Protocol Balance Sheets ![](https://5264302.fs1.hubspotusercontent-na1.net/hubfs/5264302/Demo%20Asset%20Resources/CM-Demo-balance_sheets-Cover.png) Decentralized Finance (DeFi) is a rapidly emerging ecosystem of applications and protocols used for trading, lending, and various other financial services. Rather than relying on centralized intermediaries, these protocols utilize permissionless blockchains such as Ethereum to conduct the majority of their activities and transactions on-chain. While these protocols offer an unprecedented level of transparency, complex smart contract code and overlapping on-chain transactions can be difficult to interpret. Coin Metrics **DeFi Balance Sheets** endpoint attempts to distill these operations into a traditional accounting format, presenting protocol assets and liabilities in an intuitive, easy-to-understand schema. ### Resources This notebook demonstrates basic functionality offered by the Coin Metrics Python API Client. Coin Metrics offers a vast assortment of data for hundreds of cryptoassets. The Python API Client allows for easy access to this data using Python without needing to create your own wrappers using `requests` and other such libraries. To understand the data that Coin Metrics offers, feel free to peruse the resources below. * The [Coin Metrics API v4](https://docs.coinmetrics.io/api/v4) website contains the full set of endpoints and data offered by Coin Metrics. * The [Coin Metrics Product Documentation](https://docs.coinmetrics.io/info) gives detailed, conceptual explanations of the data that Coin Metrics offers. * The [API Spec](https://coinmetrics.github.io/api-client-python/site/api_client.html) contains a full list of functions. ### File Download Download the entire notebook as either a jupyter notebook to run yourself or as a pdf from the two links below {% file src="" %} {% file src="" %} ### Notebook Setup ```python from os import environ import sys import pandas as pd import numpy as np import seaborn as sns import logging from datetime import date, datetime, timedelta from coinmetrics.api_client import CoinMetricsClient import json import logging from pytz import timezone as timezone_conv from datetime import timezone as timezone_info import matplotlib.dates as mdates from IPython.display import Markdown as md import matplotlib.pyplot as plt import requests import locale import ast %matplotlib inline ``` ```python sns.set_theme() sns.set(rc={'figure.figsize':(12,8)}) sns.set_style("whitegrid",{'axes.grid' : True,'grid.linestyle': '--', 'grid.color': 'gray','axes.edgecolor': 'white','font.family': ['arial']}) ``` ```python logging.basicConfig( format='%(asctime)s %(levelname)-8s %(message)s', level=logging.INFO, datefmt='%Y-%m-%d %H:%M:%S' ) ``` ```python # We recommend privately storing your API key in your local environment. try: api_key = environ["CM_API_KEY"] logging.info("Using API key found in environment") except KeyError: api_key = "" logging.info("API key not found. Using community client") client = CoinMetricsClient(api_key) ``` ``` 2024-10-16 09:31:03 INFO Using API key found in environment ``` ## Retrieve Balance Sheet ```python aave_v2_eth = client.get_defi_balance_sheets( defi_protocols = "aave_v2_eth", start_time = '2023-10-15', end_time = '2024-10-15').to_dataframe() # Creating Start and End Time Variables to Simplify Future Data Creation start_time = pd.to_datetime('2023-10-15') end_time = pd.to_datetime('2024-10-15') number_of_days = (end_time - start_time).days header_index = number_of_days #Showing last few rows of our current DataFrame with time parameters aave_v2_eth.tail() ``` | | defi\_protocol | block\_height | time | assets\_total\_usd | assets\_total\_count | liabilities\_total\_usd | liabilities\_total\_count | loans\_lent\_total\_usd | tvl\_total\_usd | net\_working\_capital\_usd | assets | liabilities | protocol\_utilization\_ratio | liquid\_supply\_ratio | current\_ratio | debt\_to\_assets\_ratio | | --- | -------------- | ------------- | ------------------------- | ------------------ | -------------------- | ----------------------- | ------------------------- | ----------------------- | --------------- | -------------------------- | --------------------------------------------------- | --------------------------------------------------- | ---------------------------- | --------------------- | -------------- | ----------------------- | | 362 | aave\_v2\_eth | 20938657 | 2024-10-11 00:00:00+00:00 | 1093532689.9828 | 49 | 1093614333.6095 | 49 | 351033529.7825 | 742499160.2003 | -351115173.4092 | \[{'asset': '1inch', 'total\_units': '56475.6927... | \[{'asset': '1inch', 'total\_units': '56085.2667... | 0.320985 | 0.678941 | 0.678941 | 1.000075 | | 363 | aave\_v2\_eth | 20945811 | 2024-10-12 00:00:00+00:00 | 1111063638.7613 | 49 | 1111174709.0494 | 49 | 354732076.2007 | 756331562.5606 | -354843146.4888 | \[{'asset': '1inch', 'total\_units': '56476.3058... | \[{'asset': '1inch', 'total\_units': '56085.2668... | 0.319241 | 0.68066 | 0.68066 | 1.0001 | | 364 | aave\_v2\_eth | 20952957 | 2024-10-13 00:00:00+00:00 | 1124501751.5171 | 49 | 1124630410.0842 | 49 | 357832576.4653 | 766669175.0518 | -357961235.0324 | \[{'asset': '1inch', 'total\_units': '56476.9193... | \[{'asset': '1inch', 'total\_units': '56085.2669... | 0.318178 | 0.681708 | 0.681708 | 1.000115 | | 365 | aave\_v2\_eth | 20960089 | 2024-10-14 00:00:00+00:00 | 1116858119.0506 | 49 | 1117027224.2051 | 49 | 356159715.5002 | 760698403.5504 | -356328820.6547 | \[{'asset': '1inch', 'total\_units': '56477.5331... | \[{'asset': '1inch', 'total\_units': '56085.2669... | 0.318847 | 0.681003 | 0.681003 | 1.000152 | | 366 | aave\_v2\_eth | 20967244 | 2024-10-15 00:00:00+00:00 | 1167546255.9893 | 49 | 1167839749.2056 | 49 | 365325202.3638 | 802221053.6255 | -365618695.5801 | \[{'asset': '1inch', 'total\_units': '56478.1472... | \[{'asset': '1inch', 'total\_units': '56085.2670... | 0.312822 | 0.686928 | 0.686928 | 1.000252 | ```python last_row = pd.DataFrame(aave_v2_eth.sort_values(by='time',ascending=False).iloc[0]) last_row ``` | | 366 | | ---------------------------- | --------------------------------------------------- | | defi\_protocol | aave\_v2\_eth | | block\_height | 20967244 | | time | 2024-10-15 00:00:00+00:00 | | assets\_total\_usd | 1167546255.9893 | | assets\_total\_count | 49 | | liabilities\_total\_usd | 1167839749.2056 | | liabilities\_total\_count | 49 | | loans\_lent\_total\_usd | 365325202.3638 | | tvl\_total\_usd | 802221053.6255 | | net\_working\_capital\_usd | -365618695.5801 | | assets | \[{'asset': '1inch', 'total\_units': '56478.1472... | | liabilities | \[{'asset': '1inch', 'total\_units': '56085.2670... | | protocol\_utilization\_ratio | 0.312822 | | liquid\_supply\_ratio | 0.686928 | | current\_ratio | 0.686928 | | debt\_to\_assets\_ratio | 1.000252 | ```python assets = last_row.loc["assets"].astype("str") assets = assets.apply(lambda x: ast.literal_eval(x)) assets = assets.apply(pd.Series) assets = assets.transpose() assets = pd.json_normalize(assets[header_index]) assets = assets.set_index('asset').astype(float).sort_values('tvl_usd', ascending=False) assets ``` | | total\_units | loans\_lent\_units | tvl\_units | total\_usd | loans\_lent\_usd | tvl\_usd | total\_share | loans\_lent\_share | tvl\_share | | ------------- | ------------ | ------------------ | ------------ | ------------ | ---------------- | ------------ | ------------ | ------------------ | ---------- | | asset | | | | | | | | | | | wbtc | 4.848282e+03 | 5.466126e+02 | 4.301669e+03 | 3.198977e+08 | 3.606640e+07 | 2.838313e+08 | 0.273991 | 0.098724 | 0.353807 | | steth\_lido | 1.040132e+05 | NaN | 1.040132e+05 | 2.735189e+08 | NaN | 2.735189e+08 | 0.234268 | NaN | 0.340952 | | weth | 9.980952e+04 | 3.763314e+04 | 6.217638e+04 | 2.625917e+08 | 9.901010e+07 | 1.635816e+08 | 0.224909 | 0.271019 | 0.203911 | | dai | 4.809159e+07 | 2.683005e+07 | 2.126154e+07 | 4.808146e+07 | 2.682440e+07 | 2.125706e+07 | 0.041182 | 0.073426 | 0.026498 | | usdt\_eth | 1.032573e+08 | 8.644445e+07 | 1.681281e+07 | 1.032206e+08 | 8.641379e+07 | 1.680685e+07 | 0.088408 | 0.236539 | 0.020950 | | link | 1.464885e+06 | 5.475866e+04 | 1.410127e+06 | 1.649758e+07 | 6.166937e+05 | 1.588089e+07 | 0.014130 | 0.001688 | 0.019796 | | usdc | 1.271867e+08 | 1.148692e+08 | 1.231756e+07 | 1.271589e+08 | 1.148440e+08 | 1.231486e+07 | 0.108911 | 0.314361 | 0.015351 | | aave | 4.722557e+04 | NaN | 4.722557e+04 | 7.681909e+06 | NaN | 7.681909e+06 | 0.006580 | NaN | 0.009576 | | mkr | 1.280425e+03 | 1.074842e+00 | 1.279350e+03 | 1.783592e+06 | 1.497221e+03 | 1.782095e+06 | 0.001528 | 0.000004 | 0.002221 | | crv | 2.539174e+06 | 7.895537e+03 | 2.531279e+06 | 6.821795e+05 | 2.121230e+03 | 6.800583e+05 | 0.000584 | 0.000006 | 0.000848 | | uni | 8.171202e+04 | 2.884203e+03 | 7.882782e+04 | 6.628549e+05 | 2.339690e+04 | 6.394580e+05 | 0.000568 | 0.000064 | 0.000797 | | snx | 4.090228e+05 | 2.623178e+03 | 4.063996e+05 | 6.343925e+05 | 4.068537e+03 | 6.303239e+05 | 0.000543 | 0.000011 | 0.000786 | | busd | 7.909986e+05 | 2.157098e+05 | 5.752888e+05 | 7.890753e+05 | 2.151853e+05 | 5.738900e+05 | 0.000676 | 0.000589 | 0.000715 | | frax | 5.869414e+05 | 8.315375e+04 | 5.037876e+05 | 5.850664e+05 | 8.288812e+04 | 5.021783e+05 | 0.000501 | 0.000227 | 0.000626 | | tusd | 5.113231e+05 | 1.365453e+05 | 3.747778e+05 | 5.101233e+05 | 1.362249e+05 | 3.738985e+05 | 0.000437 | 0.000373 | 0.000466 | | gusd | 5.928732e+05 | 2.691468e+05 | 3.237263e+05 | 5.923533e+05 | 2.689108e+05 | 3.234425e+05 | 0.000507 | 0.000736 | 0.000403 | | yfi | 4.882787e+01 | 5.700117e-02 | 4.877086e+01 | 2.460453e+05 | 2.872309e+02 | 2.457580e+05 | 0.000211 | 0.000001 | 0.000306 | | mana | 9.075228e+05 | 1.570493e+05 | 7.504735e+05 | 2.807515e+05 | 4.858480e+04 | 2.321667e+05 | 0.000240 | 0.000133 | 0.000289 | | rai | 7.827556e+04 | 1.651545e+04 | 6.176010e+04 | 2.383428e+05 | 5.028824e+04 | 1.880546e+05 | 0.000204 | 0.000138 | 0.000234 | | susd | 3.454224e+05 | 1.701397e+05 | 1.752826e+05 | 3.448540e+05 | 1.698598e+05 | 1.749942e+05 | 0.000295 | 0.000465 | 0.000218 | | ens | 9.499343e+03 | 3.318105e+01 | 9.466162e+03 | 1.728763e+05 | 6.038542e+02 | 1.722725e+05 | 0.000148 | 0.000002 | 0.000215 | | ust | 6.382869e+06 | 2.446807e+05 | 6.138189e+06 | 1.395150e+05 | 5.348164e+03 | 1.341669e+05 | 0.000119 | 0.000015 | 0.000167 | | pax | 2.320820e+05 | 1.059562e+05 | 1.261257e+05 | 2.318035e+05 | 1.058291e+05 | 1.259744e+05 | 0.000199 | 0.000290 | 0.000157 | | bal | 6.257505e+04 | 3.488278e+03 | 5.908677e+04 | 1.290957e+05 | 7.196507e+03 | 1.218992e+05 | 0.000111 | 0.000020 | 0.000152 | | zrx | 2.935068e+05 | 5.396759e+03 | 2.881101e+05 | 9.856175e+04 | 1.812271e+03 | 9.674948e+04 | 0.000084 | 0.000005 | 0.000121 | | lusd | 1.440150e+05 | 5.852579e+04 | 8.548924e+04 | 1.437232e+05 | 5.840718e+04 | 8.531598e+04 | 0.000123 | 0.000160 | 0.000106 | | ren | 1.739052e+06 | 6.816859e+03 | 1.732235e+06 | 6.742399e+04 | 2.642933e+02 | 6.715970e+04 | 0.000058 | 0.000001 | 0.000084 | | cvx | 3.273132e+04 | 1.463298e+02 | 3.258499e+04 | 6.226566e+04 | 2.783670e+02 | 6.198729e+04 | 0.000053 | 0.000001 | 0.000077 | | bat | 3.405090e+05 | 6.836504e+03 | 3.336725e+05 | 6.146868e+04 | 1.234126e+03 | 6.023455e+04 | 0.000053 | 0.000003 | 0.000075 | | enj | 2.973739e+05 | 9.736583e+04 | 2.000080e+05 | 4.734441e+04 | 1.550145e+04 | 3.184295e+04 | 0.000041 | 0.000042 | 0.000040 | | 1inch | 5.647815e+04 | 1.121128e+03 | 5.535702e+04 | 1.533170e+04 | 3.043444e+02 | 1.502736e+04 | 0.000013 | 0.000001 | 0.000019 | | ampl | 2.545603e+05 | 2.457468e+05 | 8.813521e+03 | 3.521378e+05 | 3.399459e+05 | 1.219190e+04 | 0.000302 | 0.000931 | 0.000015 | | knc | 3.358496e+04 | 1.393234e+04 | 1.965262e+04 | 1.582542e+04 | 6.564995e+03 | 9.260421e+03 | 0.000014 | 0.000018 | 0.000012 | | fei\_eth | 1.075374e+04 | 3.299947e+03 | 7.453792e+03 | 1.045299e+04 | 3.207657e+03 | 7.245332e+03 | 0.000009 | 0.000009 | 0.000009 | | BptBALWETH | 2.422182e-09 | NaN | 2.422182e-09 | NaN | NaN | NaN | NaN | NaN | NaN | | BptWBTCWETH | 3.185679e-03 | NaN | 3.185679e-03 | NaN | NaN | NaN | NaN | NaN | NaN | | GUniDAIUSDC | 3.743267e+00 | NaN | 3.743267e+00 | NaN | NaN | NaN | NaN | NaN | NaN | | GUniUSDCUSDT | 9.999975e-02 | NaN | 9.999975e-02 | NaN | NaN | NaN | NaN | NaN | NaN | | Univ2AAVEWETH | 1.346558e-01 | NaN | 1.346558e-01 | NaN | NaN | NaN | NaN | NaN | NaN | | Univ2CRVWETH | 4.136273e-05 | NaN | 4.136273e-05 | NaN | NaN | NaN | NaN | NaN | NaN | | Univ2DAIUSDC | 9.089043e-06 | NaN | 9.089043e-06 | NaN | NaN | NaN | NaN | NaN | NaN | | Univ2DAIWETH | 3.669936e-01 | NaN | 3.669936e-01 | NaN | NaN | NaN | NaN | NaN | NaN | | Univ2LINKWETH | 8.050459e+01 | NaN | 8.050459e+01 | NaN | NaN | NaN | NaN | NaN | NaN | | Univ2UNIWETH | 1.210293e+00 | NaN | 1.210293e+00 | NaN | NaN | NaN | NaN | NaN | NaN | | Univ2USDCWETH | 3.099794e-07 | NaN | 3.099794e-07 | NaN | NaN | NaN | NaN | NaN | NaN | | Univ2WBTCWETH | 1.887777e-07 | NaN | 1.887777e-07 | NaN | NaN | NaN | NaN | NaN | NaN | | dpi | 8.275005e+02 | 4.202049e+02 | 4.072956e+02 | NaN | NaN | NaN | NaN | NaN | NaN | | renfil | 6.387879e+03 | 6.162561e+03 | 2.253174e+02 | NaN | NaN | NaN | NaN | NaN | NaN | | xsushi | 4.261961e+05 | 3.357735e+02 | 4.258604e+05 | NaN | NaN | NaN | NaN | NaN | NaN | ```python assets_tvl_totals = assets['tvl_usd'] ``` ```python #the top 7 assets_tvl_top7 = assets_tvl_totals[:7].copy() # other assets_tvl_top7.loc['other'] = assets['tvl_usd'][7:].sum() ``` ```python df = pd.DataFrame(assets_tvl_top7) df['tvl_usd'] = df['tvl_usd'].apply(lambda x: "${:,.2f}".format((x))) df ``` | | tvl\_usd | | ----------- | --------------- | | asset | | | wbtc | $283,831,271.42 | | steth\_lido | $273,518,949.72 | | weth | $163,581,616.37 | | dai | $21,257,057.15 | | usdt\_eth | $16,806,852.06 | | link | $15,880,889.36 | | usdc | $12,314,862.37 | | other | $15,029,555.17 | ```python def my_autopct(pct): return ('%.2f' % pct + '%') if pct > 7 else '' axes = assets_tvl_top7.plot(kind='pie', autopct=my_autopct, figsize=(16, 16), subplots=True, layout=(2, 2), legend=False, labeldistance=1.1) for ax in axes.flat: yl = ax.get_ylabel() ax.set(ylabel='', title=yl) ax.set_title('Aave_v2_ETH \nEstimated TVL Share (USD) by Asset*',size=20, font='arial') fig = axes[0, 0].get_figure() fig.suptitle('\n*Assets with CM Reference Rate',size=11, font='arial') fig.tight_layout() plt.rcParams['font.size'] = 15.0 ```
```python aave_v2_eth.index = (pd.to_datetime(aave_v2_eth.time)).dt.date aave_v2_eth["Total Value Locked (USD)"] = aave_v2_eth.tvl_total_usd.astype(float) aave_tvl = aave_v2_eth[['defi_protocol','Total Value Locked (USD)']] ``` ```python aave_tvl ``` | | defi\_protocol | Total Value Locked (USD) | | ---------- | -------------- | ------------------------ | | time | | | | 2023-10-15 | aave\_v2\_eth | 1.989641e+09 | | 2023-10-16 | aave\_v2\_eth | 1.995368e+09 | | 2023-10-17 | aave\_v2\_eth | 2.032416e+09 | | 2023-10-18 | aave\_v2\_eth | 1.987327e+09 | | 2023-10-19 | aave\_v2\_eth | 1.970314e+09 | | ... | ... | ... | | 2024-10-11 | aave\_v2\_eth | 7.424992e+08 | | 2024-10-12 | aave\_v2\_eth | 7.563316e+08 | | 2024-10-13 | aave\_v2\_eth | 7.666692e+08 | | 2024-10-14 | aave\_v2\_eth | 7.606984e+08 | | 2024-10-15 | aave\_v2\_eth | 8.022211e+08 | 367 rows × 2 columns ```python ax = aave_tvl.plot.area() plt.xlim([aave_tvl.index[0], aave_tvl.index[-1]]) plt.title('\n' + str(aave_tvl.defi_protocol.iloc[0]).upper() + '\n Total Value Locked \n',fontdict={'fontsize':19.5}) ax.set_xlabel("") ax.set_ylabel("Total Value Locked (USD) \n",fontdict={'fontsize':13.5}) ax.yaxis.set_ticks(plt.gca().get_yticks()) ax.get_legend().remove() plt.gca().set_yticklabels(['${:,.2f}B'.format(x/1000000000) for x in plt.gca().get_yticks()]); ```
