Getting Started With Futures Data

import os
from os import environ
import sys
import pandas as pd
import numpy as np
import seaborn as sns
import logging
from datetime import date, datetime, timedelta
from coinmetrics.api_client import CoinMetricsClient
import json
import logging
from pytz import timezone as timezone_conv
from datetime import timezone as timezone_info
import matplotlib.ticker as mticker
from matplotlib.ticker import ScalarFormatter
from matplotlib.ticker import FuncFormatter
from matplotlib.dates import DateFormatter
import matplotlib.pyplot as plt
import matplotlib.dates as mdates
%matplotlib inline

sns.set_theme()
sns.set(rc={'figure.figsize':(8,6)})

logging.basicConfig(
    format='%(asctime)s %(levelname)-8s %(message)s',
    level=logging.INFO,
    datefmt='%Y-%m-%d %H:%M:%S'
)
now = datetime.utcnow()
last_day_date_time = now - timedelta(hours = 24)

# We recommend privately storing your API key in your local environment.
try:
    api_key = environ["CM_API_KEY"]
    logging.info("Using API key found in environment")
except KeyError:
    api_key = ""
    logging.info("API key not found. Using community client")

client = CoinMetricsClient(api_key)

2024-09-16 16:41:57 INFO     Using API key found in environment

market_reference = client.reference_data_markets(
    type='future',
    page_size=10000
).to_dataframe()

print('Total number of supported futures markets: ' + str(len(market_reference)))

Total number of supported futures markets: 18682

# Perpetual futures markets are any futures market with null expiration
print('Total number of perpetual futures markets: ' + str(len(market_reference.loc[market_reference['expiration'].isna()])))

Total number of perpetual futures markets: 4222

# Filter by base or quote asset
print('Total number of supported BTC futures markets: ' + str(len(market_reference.loc[market_reference['base'] == 'btc'])))

Total number of supported BTC futures markets: 3109

# Select first BTC futures market as an example
market_reference.loc[market_reference['base'] == 'btc'].iloc[0]

market                            binance-BTCBUSD-future
exchange                                         binance
base                                                 btc
quote                                               busd
pair                                            btc-busd
symbol                                           BTCBUSD
type                                              future
size_asset                                           btc
margin_asset                                        busd
strike                                              <NA>
option_contract_type                                <NA>
is_european                                         <NA>
contract_size                                        1.0
tick_size                                            0.1
multiplier_size                                     <NA>
listing                   2021-01-11T08:00:00.000000000Z
expiration                                          <NA>
settlement_price                                    <NA>
pool_config_id                                      <NA>
contract_address                                    <NA>
fee                                                 <NA>
price_includes_fee                                  <NA>
variable_fee                                        <NA>
base_address                                        <NA>
quote_address                                       <NA>
status                                              <NA>
order_amount_increment                             0.001
order_amount_min                                   0.001
order_amount_max                                     500
order_price_increment                                0.1
order_price_min                                    557.6
order_price_max                                4529890.0
order_size_min                                       5.0
order_taker_fee                                     <NA>
order_maker_fee                                     <NA>
margin_trading_enabled                              <NA>
experimental                                        <NA>
Name: 151, dtype: object

binance_btcusdt_oi = client.get_market_open_interest(
    markets = 'binance-BTCUSDT-future',
    start_time = datetime.utcnow() - timedelta(days=1),
).to_dataframe()

binance_btcusdt_oi

oi_catalog = client.catalog_exchange_asset_metrics_v2(metrics='open_interest_reported_future_usd').to_dataframe()
oi_catalog = oi_catalog[oi_catalog['exchange_asset'].str.split('-').str[1] == 'btc']
exchange_assets = oi_catalog['exchange_asset'].to_list()

btc_oi = client.get_exchange_asset_metrics(
    exchange_assets = exchange_assets,
    metrics = 'open_interest_reported_future_usd',
    start_time = datetime.utcnow() - timedelta(days=365),
    frequency = '1d'
).to_dataframe()

# Convert 'open_interest_reported_future_usd' to numeric
btc_oi['open_interest_reported_future_usd'] = btc_oi['open_interest_reported_future_usd'].astype(np.float64)

# Convert 'time' to datetime
btc_oi['time'] = btc_oi['time'].dt.tz_localize(None).astype('datetime64[ns]')
btc_oi

# Drop rows with missing data
btc_oi.dropna(inplace=True)

exchanges = btc_oi['exchange_asset'].unique()
dates = btc_oi['time'].unique()
stacked_data = [btc_oi[btc_oi['exchange_asset'] == exchange]['open_interest_reported_future_usd'].values for exchange in exchanges]

fig, ax = plt.subplots(figsize=(12, 7))
ax.stackplot(dates, stacked_data, labels=exchanges, edgecolor='none')

ax.set_title('\nBTC Open Interest\nby Exchange\n', fontsize=16)
ax.set_xlabel('', fontsize=14)
ax.set_ylabel('Reported Open Interest (USD)\n', fontsize=14)
ax.legend(loc='upper left', title='Exchange Asset', bbox_to_anchor=(1,1), frameon=False)
ax.grid(True, linestyle='--', alpha=0.5, color='gray')
ax.set_facecolor('white')

# Format y-axis in billions of dollars
def billions(x, pos):
    return f'${x * 1e-9:.1f}B'

ax.yaxis.set_major_formatter(FuncFormatter(billions))

ax.set_xlim([btc_oi['time'].min(), btc_oi['time'].max()])
ax.xaxis.set_major_locator(mdates.MonthLocator())
ax.xaxis.set_major_formatter(mdates.DateFormatter('%b\n%Y'))
fig.autofmt_xdate()
ax.tick_params(axis='x', which='major', pad=10)
_ = plt.xticks(rotation=0)
plt.tight_layout()
plt.show()

market = 'binance-BTCUSDT-future'

liquidations_df = client.get_market_liquidations(
    markets = market,
    start_time = datetime.utcnow() - timedelta(days=1),
).to_dataframe()
liquidations_df['amount'] = liquidations_df['amount'].astype(np.float64)
liquidations_df['price'] = liquidations_df['price'].astype(np.float64)

liquidations_df.head()

# Get volume-weighted average price of the futures contract from the market-candles endpoint
price = client.get_market_candles(
        markets = market,
        start_time = datetime.utcnow() - timedelta(days=1),
        end_time = datetime.utcnow(),
        frequency='1m'
).to_dataframe()
price['vwap'] = price['vwap'].astype(np.float64)

import matplotlib.pyplot as plt
from matplotlib.dates import DateFormatter

plt.figure(figsize=(13,7))
scaling_factor = 300  # Adjust this value to get the desired point size
color_map = {'buy': 'green', 'sell': 'red'}
liqs = plt.scatter(
    x=liquidations_df['time'],
    y=liquidations_df['price'],
    s=liquidations_df['amount'] * scaling_factor,  # Scale point sizes by the scaling factor
    c=liquidations_df['side'].map(color_map),
    alpha=0.6
)

plt.plot(price['time'], price['vwap'], color='black', linestyle='-', label='VWAP')

mean_price = liquidations_df['price'].mean()
std_price = liquidations_df['price'].std()
plt.ylim(mean_price - 3*std_price, mean_price + 3*std_price)
plt.xlabel("", fontsize=15)
plt.ylabel("Price\n", font='arial',fontsize=15)
plt.title('\n' + str(market) + '\nLiquidations\n', size=20)

# Format the xtick labels
date_format = DateFormatter('%D\n%H:%M')
plt.gca().xaxis.set_major_formatter(date_format)

legend_labels = ['BUY', 'SELL', 'VWAP']
legend_handles = [
    plt.Line2D([0], [0], marker='o', color='w', markerfacecolor=color_map['buy'], markersize=12),
    plt.Line2D([0], [0], marker='o', color='w', markerfacecolor=color_map['sell'], markersize=12),
    plt.Line2D([0], [0], color='black', lw=2)  # Legend entry for VWAP
]
legend = plt.legend(legend_handles, legend_labels, loc='lower right', fontsize=14, ncol=2, framealpha=0, bbox_to_anchor=(0.99, 1.02))

plt.gca().set_facecolor('white')
plt.grid(color='black', linestyle='dotted')

plt.tight_layout()
plt.show()

metrics = ['liquidations_reported_future_buy_usd_1h', 'liquidations_reported_future_sell_usd_1h']

liq_catalog = client.catalog_exchange_asset_metrics_v2(metrics=metrics).to_dataframe()
liq_catalog = liq_catalog[liq_catalog['exchange_asset'].str.split('-').str[1] == 'btc']
liq_catalog

agg_liqs = client.get_exchange_asset_metrics(
    exchange_assets=liq_catalog['exchange_asset'].to_list(),
    metrics = metrics,
    start_time = datetime.utcnow() - timedelta(days=1.5),
    frequency='1h'
).to_dataframe()
agg_liqs.replace('None', np.nan, inplace=True)
agg_liqs[metrics[0]] = agg_liqs['liquidations_reported_future_buy_usd_1h'].astype(np.float64)
agg_liqs['liquidations_reported_future_sell_usd_1h'] = -1 * agg_liqs['liquidations_reported_future_sell_usd_1h'].astype(np.float64)

agg_liqs = agg_liqs.fillna(0)
agg_liqs

btc_total_oi = client.get_asset_metrics(
    assets='btc',
    metrics='open_interest_reported_future_usd',
    frequency='1h',
    start_time = datetime.utcnow() - timedelta(days=2)
).to_dataframe()
btc_total_oi.head()

df = agg_liqs

melted_df = df.melt(id_vars=['time', 'exchange_asset'],
                    value_vars=['liquidations_reported_future_buy_usd_1h', 'liquidations_reported_future_sell_usd_1h'],
                    var_name='transaction_type', value_name='amount')
melted_df['amount'] /= 1e6
melted_df['time'] = melted_df['time'].dt.tz_localize(None)

fig, ax = plt.subplots(figsize=(12,7))
plt.gca().set_facecolor('white')
plt.grid(color='gray', linestyle='dotted',alpha=0.3)
ax2 = ax.twinx()

unique_assets = melted_df['exchange_asset'].unique()
colormap = plt.cm.tab20
colors = {asset: colormap(i) for i, asset in enumerate(unique_assets)}

for asset in unique_assets:
    subset = melted_df[melted_df['exchange_asset'] == asset]
    ax.bar(subset['time'], subset['amount'], width=0.01, label=asset, color=colors[asset])

# Plot open interest on secondary y-axis
btc_total_oi['time'] = btc_total_oi['time'].dt.tz_localize(None)
ax2.plot(btc_total_oi['time'], btc_total_oi['open_interest_reported_future_usd'], color='black', label='Open Interest (USD)', linewidth=1, linestyle='--')

ax.set_xlabel('')
ax.set_ylabel('Amount Liquidated (USD)', fontsize=14)
ax2.set_ylabel('\nOpen Interest (USD)', fontsize=14)
ax.set_title('\nBTC Hourly Liquidations \nand Open Interest (USD)\n', fontsize=16)

locator = mdates.HourLocator(interval=6)
ax.xaxis.set_major_locator(locator)
ax.xaxis.set_major_formatter(mdates.DateFormatter('%D\n%H:%M'))

# Format y-axis ticks for liquidations
def y_formatter(x, pos):
    if x < 0:
        return f"-${abs(x):.1f}M"
    else:
        return f"${x:.1f}M"

ax.yaxis.set_major_formatter(mticker.FuncFormatter(y_formatter))
ax.yaxis.grid(True, linestyle='--', which='major')
ax2.yaxis.grid(False)
ax.yaxis.tick_left()
ax.tick_params(axis='both', length=0, labelsize=12)
ax2.tick_params(axis='both', length=0, labelsize=12)

# Format y-axis ticks for open interest in billions
def y_formatter_billion(x, pos):
    return f"${x*1e-9:.2f}B"
ax2.yaxis.set_major_formatter(mticker.FuncFormatter(y_formatter_billion))

num_ticks = 10
yticks = np.linspace(melted_df['amount'].min(), melted_df['amount'].max(), num_ticks)
ax.set_yticks(yticks)

# Set y-ticks based on a similar range
yticks2 = np.linspace(btc_total_oi['open_interest_reported_future_usd'].min(),
                      btc_total_oi['open_interest_reported_future_usd'].max(), num_ticks)
ax2.set_yticks(yticks2)

# Legend for both axes
lines, labels = ax.get_legend_handles_labels()
lines2, labels2 = ax2.get_legend_handles_labels()
ax2.legend(lines + lines2, labels + labels2, loc='upper right', fontsize=10, ncol=2, framealpha=0, bbox_to_anchor=(1.08, 1.19))

plt.tight_layout()

for spine in ax2.spines.values():
    spine.set_visible(False)
for spine in ax.spines.values():
    spine.set_visible(False)

plt.show()

fr_catalog = client.catalog_market_funding_rates_v2(exchange='binance').to_dataframe()

fr_catalog

fr_markets = [
    'bitmex-XBTUSD-future',
    'bybit-BTCUSD-future',
    'okex-BTC-USD-SWAP-future'
]

fr_raw = client.get_market_funding_rates(
    markets = fr_markets,
    start_time=datetime.utcnow() - timedelta(days=7),
).to_dataframe()
fr_raw

# Convert 'time' to datetime for plotting, if not already in this format
fr_raw['time'] = pd.to_datetime(fr_raw['time'])
fr_raw = fr_raw.sort_values(by='time')
for column in fr_raw.columns:
    if column not in ['time', 'market']:
        fr_raw[column] = pd.to_numeric(fr_raw[column], errors='coerce') * 100

# Create a color map
markets = fr_raw['market'].unique()
colors = plt.cm.jet(np.linspace(0, 1, len(markets)))  # Generating a color for each market
color_map = dict(zip(markets, colors))

# Plotting
plt.figure(figsize=(15, 6))
plt.gca().set_facecolor('white')
# Plot bars for each market
for market in markets:
    market_data = fr_raw[fr_raw['market'] == market]
    plt.bar(market_data['time'], market_data['rate'], color=color_map[market], label=market, width=0.07, alpha=0.9)

formatter = mticker.FuncFormatter(lambda y, _: '{:.4f}%'.format(y))
plt.gca().yaxis.set_major_formatter(formatter)
plt.grid(True, linestyle='--', which='major', color='gray', alpha=0.3)
plt.xticks(rotation=45)
plt.xlabel('')
plt.ylabel('Funding Rate (%)')
plt.title('\nPerpetual Futures\n Funding Rates\n',fontsize=16)
plt.legend(loc='upper left', fontsize=10, bbox_to_anchor=(0.76,1.2), frameon=False)

plt.show()

btc_fr = client.get_asset_metrics(
    assets='btc',
    start_time='2023-10-01',
    metrics = [
        'futures_aggregate_funding_rate_all_margin_1d_period',
        'futures_aggregate_funding_rate_all_margin_30d_period',
        'futures_aggregate_funding_rate_all_margin_1y_period'
        ]
).to_dataframe()

btc_fr.head()

plt.figure(figsize=(14, 8))

plt.plot(btc_fr['time'], btc_fr['futures_aggregate_funding_rate_all_margin_1d_period'] * 100, label='1D Period', color='blue')
plt.plot(btc_fr['time'], btc_fr['futures_aggregate_funding_rate_all_margin_30d_period'] * 100, label='30D Period', color='green')
plt.plot(btc_fr['time'], btc_fr['futures_aggregate_funding_rate_all_margin_1y_period'] * 100, label='1Y Period', color='red')

plt.gca().set_facecolor('white')
plt.grid(color='gray', linestyle='dotted', alpha=0.3)

plt.title('Bitcoin Perpetual Futures\nAggregated Funding Rate\n', fontsize=16)
plt.xlabel('')
plt.ylabel('Aggregate\nFunding Rate\n', fontsize=14)
plt.grid(True, alpha=0.3, linestyle='--')

# Set the formatter for the Y-axis to display percentages
formatter = mticker.FuncFormatter(lambda y, _: '{:.0f}%'.format(y))
plt.gca().yaxis.set_major_formatter(formatter)

plt.gca().xaxis.set_major_locator(mdates.AutoDateLocator())
plt.gca().xaxis.set_major_formatter(mdates.ConciseDateFormatter(mdates.AutoDateLocator()))
plt.legend(loc='upper right', fontsize=10, ncol=1, framealpha=0, bbox_to_anchor=(0.99, 1.13))
plt.show()

btc_exch_fr_catalog = client.catalog_exchange_asset_metrics_v2(metrics='futures_aggregate_funding_rate_all_margin_1y_period').to_dataframe()
btc_exch_fr_catalog = btc_exch_fr_catalog.loc[btc_exch_fr_catalog['metric']=='futures_aggregate_funding_rate_all_margin_1y_period']
btc_exch_fr_catalog = btc_exch_fr_catalog[btc_exch_fr_catalog['exchange_asset'].str.contains(r'-btc$', case=False)]
btc_exch_fr_catalog

2024-09-16 16:42:29 WARNING  /catalog/ endpoints will be deprecated in the future. Consider using /catalog-v2/ and /reference-data/ endpoints instead.

btc_fr_exchanges = client.get_exchange_asset_metrics(
    exchange_assets=btc_exch_fr_catalog['exchange_asset'].to_list(),
    start_time='2023-01-01',
    end_time='2023-12-31',
    metrics = 'futures_aggregate_funding_rate_all_margin_1y_period',
    frequency='1d'
).to_dataframe()
btc_fr_exchanges

df = btc_fr_exchanges
pivot_df = df.pivot(index='exchange_asset', columns='time', values='futures_aggregate_funding_rate_all_margin_1y_period')
pivot_df = pivot_df.astype(float)
pivot_df

# Plotting the heatmap
plt.figure(figsize=(16, 8))
ax = sns.heatmap(pivot_df, cmap='viridis', annot=False)
plt.title('BTC Perp Futures\nAggregate Funding Rate (APR)\n', fontsize=14)

# Set x-ticks for monthly intervals
date_labels = [pd.to_datetime(label).strftime('%b %Y') for label in pivot_df.columns]
monthly_intervals = [i for i, label in enumerate(pivot_df.columns) if pd.to_datetime(label).day == 1]

ax.set_xticks(monthly_intervals)
ax.set_xticklabels([date_labels[i] for i in monthly_intervals], rotation=0)
ax.set_yticklabels(ax.get_yticklabels(), rotation=0)

# Formatting colorbar labels as percentages
colorbar = ax.collections[0].colorbar
colorbar.ax.yaxis.set_major_formatter(mticker.FuncFormatter(lambda x, _: f'{x:.0%}'))

plt.xlabel('')
plt.ylabel('')
plt.show()

btc_cumulative_fr = client.get_asset_metrics(
    assets='btc',
    start_time='2023-01-01',
    end_time='2023-12-31',
    metrics = [
        'futures_cumulative_funding_rate_all_margin_rolling_1d',
        'futures_cumulative_funding_rate_all_margin_rolling_7d',
        'futures_cumulative_funding_rate_all_margin_rolling_30d'
        ]
).to_dataframe()
btc_cumulative_fr.head()

for column in btc_cumulative_fr.columns:
    if column != 'time':
        btc_cumulative_fr[column] = pd.to_numeric(btc_cumulative_fr[column], errors='coerce')

# Convert the 'time' column to datetime format if it's not already
btc_cumulative_fr['time'] = pd.to_datetime(btc_cumulative_fr['time'], errors='coerce')

# Ensure 'futures_cumulative_funding_rate_all_margin_7d' is numeric, replacing non-numeric values with numpy.nan
btc_cumulative_fr['futures_cumulative_funding_rate_all_margin_7d'] = pd.to_numeric(btc_cumulative_fr['futures_cumulative_funding_rate_all_margin_rolling_7d'], errors='coerce')

# Plotting with safe checking
valid_7d_indices = ~btc_cumulative_fr['futures_cumulative_funding_rate_all_margin_rolling_7d'].isna()
valid_30d_indices = ~btc_cumulative_fr['futures_cumulative_funding_rate_all_margin_rolling_30d'].isna()

plt.plot(btc_cumulative_fr['time'], btc_cumulative_fr['futures_cumulative_funding_rate_all_margin_rolling_1d'] * 100, label='1D Period', color='blue')
plt.plot(btc_cumulative_fr['time'][valid_7d_indices], btc_cumulative_fr['futures_cumulative_funding_rate_all_margin_rolling_7d'][valid_7d_indices] * 100, label='7D Period', color='green')
plt.plot(btc_cumulative_fr['time'][valid_30d_indices], btc_cumulative_fr['futures_cumulative_funding_rate_all_margin_rolling_30d'][valid_30d_indices] * 100, label='30D Period', color='red')

plt.gca().set_facecolor('white')
plt.grid(color='gray', linestyle='dotted', alpha=0.3)

plt.title('Bitcoin Perpetual Futures\nCumulative Funding Rate\n', fontsize=16)
plt.xlabel('')
plt.ylabel('Cumulative\nFunding Rate\n', fontsize=14)
plt.grid(True, alpha=0.3, linestyle='--')

formatter = mticker.FuncFormatter(lambda y, _: '{:.2f}%'.format(y))
plt.gca().yaxis.set_major_formatter(formatter)
plt.gca().xaxis.set_major_locator(mdates.AutoDateLocator())
plt.gca().xaxis.set_major_formatter(mdates.ConciseDateFormatter(mdates.AutoDateLocator()))
plt.legend(loc='upper right', fontsize=10, ncol=1, framealpha=0, bbox_to_anchor=(0.99, 1.13))
plt.show()
