Comparing Volumes of Exchanges and Assets

Though decentralized finance has garnered significant attention in recent years, centralized exchanges remain a crucial cornerstone of the crypto asset industry. These trading venues serve as some of the deepest pools of liquidity for the top crypto assets, and facilitate the onboarding and offboarding of millions of users by sitting at the intersection of digital assets and fiat currencies. Coin Metrics collects a wide variety of data from a universe of 39+ top crypto exchanges, allowing our users to easily assess exchange dominance, asset trading volumes, and even the composition of trading patterns in specific markets.

Resources

This notebook demonstrates basic functionality offered by the Coin Metrics Python API Client and Market Data Feed.

Coin Metrics offers a vast assortment of data for hundreds of cryptoassets. The Python API Client allows for easy access to this data using Python without needing to create your own wrappers using requests and other such libraries.

To understand the data that Coin Metrics offers, feel free to peruse the resources below.

The Coin Metrics API v4 website contains the full set of endpoints and data offered by Coin Metrics.
The Coin Metrics Product Documentation gives detailed, conceptual explanations of the data that Coin Metrics offers.
The API Spec contains a full list of functions.

File Download

Download the entire notebook as either a jupyter notebook to run yourself or as a pdf from the two links below

Notebook Setup

from os import environ
import sys
import pandas as pd
import numpy as np
import logging
from datetime import date, datetime, timedelta
from coinmetrics.api_client import CoinMetricsClient
import json
import logging
import matplotlib.pyplot as plt
# import plotly.express as px
# import seaborn as sns
%matplotlib inline

logging.basicConfig(
    format='%(asctime)s %(levelname)-8s %(message)s',
    level=logging.INFO,
    datefmt='%Y-%m-%d %H:%M:%S'
)

# We recommend privately storing your API key in your local environment.
try:
    api_key = environ["CM_API_KEY"]
    logging.info("Using API key found in environment")
except KeyError:
    api_key = ""
    logging.info("API key not found. Using community client")
client = CoinMetricsClient(api_key)

2024-10-07 12:48:33 INFO     Using API key found in environment

Daily Exchange Volumes

Coin Metrics creates aggregated metrics to allow users to easily compare the total trading volume of dominant centralized exchanges. By leveraging the timeseries/exchange-metrics endpoint, we can retrieve the daily reported spot trading volume for a single trading venue or a list of exchanges.

end = pd.to_datetime(datetime.now())
start = end - timedelta(days=28)

exchange_list = [
    e['exchange'] for e in client.get_snapshots_of_asset_metric_constituents(
        'volume_trusted_spot_usd_1d', at_time=end
    ).to_list()
]

volumes = client.get_exchange_metrics(
    exchanges=exchange_list,
    metrics='volume_reported_spot_usd_1d',
    frequency='1d',
    start_time=start,
    end_time=end
).to_dataframe()

top_volumes = volumes.groupby('exchange')['volume_reported_spot_usd_1d'].sum().sort_values(ascending=False)
volumes['exchange'] = np.where(volumes['exchange'].isin(top_volumes[:8].index), volumes['exchange'], 'other')

volumes = volumes.groupby(['exchange', 'time'])[['volume_reported_spot_usd_1d']].sum().reset_index()
exchange_list_truncated = list(volumes.exchange.unique())

pivot_volumes = volumes.pivot(
    index="time",
    columns="exchange",
    values="volume_reported_spot_usd_1d"
)

pivot_volumes.head()

pivot_volumes[exchange_list_truncated]

def format_ticks_usd(y, pos):
    if y >= 1_000_000_000_000:
        return '${:.1f}T'.format(y/1000000000000)
    elif y >= 1_000_000_000:
        return '${:.1f}B'.format(y/1000000000)
    elif y >= 1000000:
        return '${:.1f}M'.format(y/1000000)
    elif y >= 1000:
        return '${:.1f}K'.format(y/1000)
    else:
        return '${:.1f}'.format(y)

fig, ax = plt.subplots(figsize=(8,6))

ax.stackplot(
    pivot_volumes.index,
    [pivot_volumes[exchange].astype(float) for exchange in exchange_list_truncated],
    labels=exchange_list_truncated,
)
ax.set_title("Total Exchange Volume")
ax.yaxis.set_major_formatter(format_ticks_usd)
ax.yaxis.grid(visible=True, which='major', linestyle='--', alpha=0.5)
ax.legend(loc='lower right', bbox_to_anchor=(1.25, 0), title="Exchange")
ax.tick_params(axis='x', labelrotation=45)
ax.xaxis.set_major_locator(plt.MaxNLocator(4))
ax.set_xlim(volumes.time.min(), volumes.time.max())

pivot_volume_share = 100*pivot_volumes[exchange_list_truncated].div(pivot_volumes[exchange_list_truncated].sum(axis=1), axis=0)

import matplotlib.ticker as mtick


fig, ax = plt.subplots(figsize=(8,6))

ax.stackplot(
    pivot_volume_share.index,
    [pivot_volume_share[exchange].astype(float) for exchange in exchange_list_truncated],
    labels=exchange_list_truncated,
)
ax.set_title("Exchange Volume Share")
ax.yaxis.set_major_formatter(mtick.PercentFormatter())
ax.yaxis.grid(visible=True, which='major', linestyle='--', alpha=0.5)
ax.legend(loc='lower right', bbox_to_anchor=(1.25, 0), title="Exchange")
ax.tick_params(axis='x', labelrotation=45)
ax.xaxis.set_major_locator(plt.MaxNLocator(4))
ax.set_xlim(volumes.time.min(), volumes.time.max())
ax.set_ylim(0, 100)

In addition to retrieving aggregated trading volumes for all markets on an exchange, we can also utilize the timeseries/market-candles to obtain the USD trading volume of individual markets on a particular exchange.

# The wildcard parameter (*) enables users to retrieve all markets matching the designated format
exchange = 'coinbase'
markets=f"{exchange}-*-spot"

df = client.get_market_candles(
    markets=markets,
    start_time=start,
    end_time=end,
    frequency='1d',
    page_size=10000
).parallel(time_increment=timedelta(days=1)).to_dataframe()

Exporting to dataframe type:  79%|███████████████████████████████████████▎          | 22/28 [00:02<00:00, 10.38it/s]2024-10-07 12:48:38 INFO     no data to export
Exporting to dataframe type: 100%|██████████████████████████████████████████████████| 28/28 [00:02<00:00,  9.86it/s]

df

11032 rows × 10 columns

df["candle_usd_volume"] = df.candle_usd_volume.astype(float)
df["time"] = pd.to_datetime(df.time)

df.sort_values(["market","time"],inplace=True)

# Create Addt. Cols
df['exchange'] = df.market.apply(lambda x: x.split("-")[0])
df['exchange-base'] = df.market.apply(lambda x: x.split("-")[0]+"-"+x.split("-")[1])
df['market_type'] = df.market.apply(lambda x: x.split("-")[-1])
df['base'] = df.market.apply(lambda x: x.split("-")[1])
df['quote'] = df.market.apply(lambda x: x.split("-")[2])

# Get volume by base asset by day

# Get top 10 assets by volume
total_vol_by_base = df.groupby('base',as_index=False).candle_usd_volume.sum()
total_vol_by_base.sort_values(by="candle_usd_volume",inplace=True)
base_top_list = total_vol_by_base.tail(10).base.tolist()
df["base2"] = np.where(df.base.isin(base_top_list),df.base,f"{len(total_vol_by_base)-10} others")

# Get sum by base asset by day
df_vol_by_base = df.groupby(["time","base2"],as_index=False).candle_usd_volume.sum()
df_vol_by_base['total_vol'] = df_vol_by_base.groupby("time").candle_usd_volume.transform(sum)
df_vol_by_base.columns=["time","base_asset","vol","total_vol"]
df_vol_by_base["vol_pct"]=(df_vol_by_base.vol/df_vol_by_base.total_vol)*100
df_vol_by_base.sort_values(["base_asset","time"],inplace=True)

df_vol_by_base

297 rows × 5 columns

num_assets = len(total_vol_by_base)
top_assets  = df_vol_by_base[~df_vol_by_base.base_asset.isin(["btc","eth",f"{num_assets-10} others"])].groupby("base_asset").vol.sum().sort_values(ascending=False).index.tolist()
top_assets  = ["btc","eth",f"{num_assets-10} others"] + top_assets

# Pivot back to assets in columns
df_vol_pivot = df_vol_by_base.pivot(index='time',
                             columns="base_asset",
                             values="vol_pct")

df_vol_pivot = df_vol_pivot[top_assets]
df_vol_pivot

fig, ax = plt.subplots(figsize=(8,6))

ax.stackplot(
    df_vol_pivot.index,
    [df_vol_pivot[asset].astype(float) for asset in df_vol_by_base.base_asset.unique()],
    labels=df_vol_by_base.base_asset.unique(),
)
ax.set_title("Asset Volume Share")
ax.yaxis.set_major_formatter(mtick.PercentFormatter())
ax.yaxis.grid(visible=True, which='major', linestyle='--', alpha=0.5)
ax.legend(loc='lower right', bbox_to_anchor=(1.25, 0), title="Asset")
ax.tick_params(axis='x', labelrotation=45)
ax.xaxis.set_major_locator(plt.MaxNLocator(4))
ax.set_xlim(volumes.time.min(), volumes.time.max())
ax.set_ylim(0, 100)

Retrieve Trade Sizes

Trade size is a useful metric for understanding the composition of an exchange's trading patterns. Is the platform more popular for retail traders, or large institutions? Which assets are driven by whale trades vs. small buys? These patterns are especially relevant for venues like Coinbase, where fee revenue is determined by trade size.

def get_trade_size_stats(start,end,market):
    """
    For a given date and market, get stats on number of trades and dist of trade sizes
        Returns a df with:
             Number of trades
             Volume (USD/Native)
             Number of trades by size groupings
             Volume derived from trades of various size groupings
    """

    #Call api
    df_trades = client.get_market_trades(
        markets=market,
        start_time=start,
        end_time=end,
        page_size=10000
    ).parallel(time_increment=timedelta(hours=1)).to_dataframe()
    #Prep data
    df_trades["amount_usd"] = df_trades.amount*df_trades.price
    df_trades["amount_usd_groups"] = pd.cut(df_trades["amount_usd"],bins=[0,1e3,1e4,1e5,1e6,1e7,1e100])
    print(df_trades.time.min())
    print(df_trades.time.max())

    #Get stats by group
    sum_count_by_size = df_trades.groupby("amount_usd_groups").agg({"amount_usd":['count',sum]})

    #Collect into a df
    df_day = pd.DataFrame()

    df_day.loc[start,"NumTrades"] = len(df_trades)
    df_day.loc[start,"VolUSD"] = df_trades.amount_usd.sum()
    df_day.loc[start,"VolNTV"] = df_trades.amount.sum()

    df_day.loc[start,"AvgSizeUSD"] = df_trades.amount_usd.mean()
    df_day.loc[start,"MedSizeUSD"] = df_trades.amount_usd.median()
    df_day.loc[start,"MaxSizeUSD"] = df_trades.amount_usd.max()

    df_day.loc[start,"NumTrades_0-1K"]      = sum_count_by_size.iloc[0,0]
    df_day.loc[start,"NumTrades_1K-10K"]    = sum_count_by_size.iloc[1,0]
    df_day.loc[start,"NumTrades_10K-100K"]  = sum_count_by_size.iloc[2,0]
    df_day.loc[start,"NumTrades_100K-1M"]   = sum_count_by_size.iloc[3,0]
    df_day.loc[start,"NumTrades_1M-10M"]    = sum_count_by_size.iloc[4,0]
    df_day.loc[start,"NumTrades_10M-Over"]  = sum_count_by_size.iloc[5,0]

    df_day.loc[start,"VolUSD_Trades_0-1K"]     = sum_count_by_size.iloc[0,1]
    df_day.loc[start,"VolUSD_Trades_1K-10K"]   = sum_count_by_size.iloc[1,1]
    df_day.loc[start,"VolUSD_Trades_10K-100K"] = sum_count_by_size.iloc[2,1]
    df_day.loc[start,"VolUSD_Trades_100K-1M"]  = sum_count_by_size.iloc[3,1]
    df_day.loc[start,"VolUSD_Trades_1M-10M"]   = sum_count_by_size.iloc[4,1]
    df_day.loc[start,"VolUSD_Trades_10M-Over"] = sum_count_by_size.iloc[5,1]

    return df_day

start = datetime.today() - timedelta(hours=24)
end = datetime.today()

df = get_trade_size_stats(start, end,'coinbase-btc-usd-spot')

Exporting to dataframe type:  44%|██████████████████████                            | 11/25 [00:02<00:02,  6.99it/s]2024-10-07 12:48:43 INFO     no data to export
Exporting to dataframe type: 100%|██████████████████████████████████████████████████| 25/25 [00:04<00:00,  5.16it/s]

2024-10-06 12:48:39.766637+00:00
2024-10-07 12:48:31.860605+00:00

df.head()

df.transpose()#.rename_axis('value')

trade_sizes = df[['VolUSD_Trades_0-1K',
                  'VolUSD_Trades_1K-10K',
                  'VolUSD_Trades_10K-100K',
                  'VolUSD_Trades_100K-1M',
                  'VolUSD_Trades_1M-10M',
                  'VolUSD_Trades_10M-Over']]

trade_sizes = trade_sizes.rename(columns=lambda x: x.split('_')[2])
trade_sizes

fig, ax = plt.subplots()
ax.bar(
    x=trade_sizes.columns,
    height=np.hstack([trade_sizes[c].astype(float) for c in trade_sizes.columns])
)

ax.set_title(f"Coinbase Volume by Trade Size \n{start.isoformat()[:16]} to {end.isoformat()[:16]}")
ax.yaxis.set_major_formatter(format_ticks_usd)
ax.yaxis.grid(visible=True, which='major', linestyle='--', alpha=0.5)
